Overall
- Total pieces 1
-
Included accessories
• (1) Wall Mounting Template
• (1) Paintable Magnetic Grille - Optional accessories • (1) Rough-in-kit
- Cabinet warranty 5 years
- Drivers warranty 5 years
- Carton 1 6.75" (17.15 cm) h x 19.5" (49.53 cm) w x 10.38" (26.37 cm) d - 12 lbs (5.44 kg)
In-Wall and In-Ceiling
- Qty included 1
- Availability US
-
Driver complement
• (1) 1" (2.54 cm) d (Round) - Tweeter
• (2) 6.5" (16.51 cm) d (Round) BDSS Bass/Mid - Mid/Woofer - Grille dimensions 17.13" (43.51 cm) h x 8.31" (21.11 cm) w
- Available orientations Vertical
- Shape Rectangle
- Dimensions 16.19" (41.12 cm) h x 7.38" (18.75 cm) w
- Flush mounting depth 3.13" (7.95 cm) -
- Type A/V Receiver Crossover Setting
- A/V receiver crossover settings Small (40 Hz)
- Total frequency response 26 Hz → 30,000 Hz
- Nominal impedance 8 ohms
- Max sensitivity (1 watt @ 1 meter) 90 dB
- Audio inputs
- Speaker inputs (1) Pair of Heavy Duty, Spring Loaded - na
