I decided to use one of my extra bedrooms for my listening room/wifes gaming area. Its a basic setup that is almost complete. The tv will be mounted on the wall, I may or may not get this equipment shelf http://www.bestbuy.com/site/Whalen+F...9#tab=overview to replace the tv stand, and I will be getting the ikea ponag chair http://www.ikea.com/us/en/catalog/pr...28/#/S79903930

I hooked it all up and after a few adjustments It sounds good. I think I will need to make some acoustic panels. certain frequencies have odd effects in the room. It can get uncomfortable to listen to. I found out quickly that having the speakers near the back wall greatly inflates the midrange and makes everything sound muffled. If you have any ideas on where to start with placing panels let me know. I am researching the subject currently.

I am really happy with the way it came out. Looks better then I thought it would.

[chumlie]

Congrats !!! Enjoy your new room.

[ViperZ]

Definitely need at least 4 panels - one behind each speaker, and one at the first reflection point for each speaker.

[Clipdat]

I'm sorry, you lost me at "wife's gaming area" - please, go on!

[organ]

Sweet set up man. I also have the LSi9 but in cherry. After seeing pics like yours of the ebony, I'm beginning to think I should have went for that color.

Have you tried corner loading the subs?

[outlander]

The room looks great, if you want to keep the room to yourself for serious listening, lose the TV. I have a dedicated listening room with no TV and nobody goes in that room but me because they sure don’t want to just sit and listen to music.
O

[brianle]

Congrats in your new room. Enjoy!

[wkjeffers]

check out GIK acoustics, they are affordable and can provide friendly advice if you call them. for $50 per panel, you can spend more time listening and less time stapling.

[pablo_rodz]

Definitely need at least 4 panels - one behind each speaker, and one at the first reflection point for each speaker.

By 1st reflection point, do you mean on the walls next to the speakers?

[DSkip]

By 1st reflection point, do you mean on the walls next to the speakers?

Essentially, yes. Go to GIK acoustics and read through some of their articles. They do a really good job explaining what you are looking for when adding room treatments.

[Mikey081057]

nice room

enjoy

[specd_out]

I'm sorry, you lost me at "wife's gaming area" - please, go on!

Yea she plays COD and battlefield with me online

Sweet set up man. I also have the LSi9 but in cherry. After seeing pics like yours of the ebony, I'm beginning to think I should have went for that color.
They actually are not ebony. I removed the sides for re-staining. They are naked at the moment

Have you tried corner loading the subs?

No but after the success of doing that in my HT rig I have considered it for this room

The room looks great, if you want to keep the room to yourself for serious listening, lose the TV. I have a dedicated listening room with no TV and nobody goes in that room but me because they sure don’t want to just sit and listen to music.
O

I would but my wife needs a gaming area, and I enjoy bluray concerts, so I use the tv to watch those as well.

Essentially, yes. Go to GIK acoustics and read through some of their articles. They do a really good job explaining what you are looking for when adding room treatments.

Thanks for the info. I will check them out

[PSOVLSK]

First reflection point will be tough with the window. I have that problem in my 2-channel room.

Also, either you have too much toe-in or I don't have enough. Since no one else has mentioned anything, I'm leaning towards I don't have enough. But I guess if yours sounds good to you and mine sounds good to me it doesn't really matter.

Nice set-up. Enjoy!

[ViperZ]

First reflection point will be tough with the window. I have that problem in my 2-channel room.

Also, either you have too much toe-in or I don't have enough. Since no one else has mentioned anything, I'm leaning towards I don't have enough. But I guess if yours sounds good to you and mine sounds good to me it doesn't really matter.

Nice set-up. Enjoy!

Can always use a stand-based 'portable' panel in front of the window or hang it with the curtains :)

Too much toe-in will most likely zero-in on a single listening chair (sweet spot)

[RamZet]

Very cool. Im debating about adding a TV to my listening room.

[marvda1]

just sit back, close your eyes and sip on some wild turkey, you don't need a tv

[ken brydson]

just sit back, close your eyes and sip on some wild turkey, you don't need a tv

^ This, don't know about wild turkey though... Just beverage of choice would be my suggestion^

[recoveryone]

I'm new here, but some quick observation I would say the room is only about a 10 x 12 maybe? if that is the case or smaller, I would remove one of the subs. That is what is causing the extra mid range and muffled sound. Subs support those mid to low Hz ranges that can be taken as the fronts are two close to rear wall or making the sound seem uneven. The ideal is to have your speakers set evenly across the front stage so each speaker will reach the listener at the same time. Another way to combat this is use the speaker distance guide to help reduce or enhance each speakers presance within the setup. I see you have the Pioneer VSX 91TX series that comes with the auto EQ mic setup. I would run that and see if it can adjust those levels for you, then if you still have those sound issues remove one one of the subs and do the same with the mic setup.

[Inspector 24]

Spiked speaker stands?

[specd_out]

I'm new here, but some quick observation I would say the room is only about a 10 x 12 maybe? if that is the case or smaller, I would remove one of the subs. That is what is causing the extra mid range and muffled sound. Subs support those mid to low Hz ranges that can be taken as the fronts are two close to rear wall or making the sound seem uneven. The ideal is to have your speakers set evenly across the front stage so each speaker will reach the listener at the same time. Another way to combat this is use the speaker distance guide to help reduce or enhance each speakers presance within the setup. I see you have the Pioneer VSX 91TX series that comes with the auto EQ mic setup. I would run that and see if it can adjust those levels for you, then if you still have those sound issues remove one one of the subs and do the same with the mic setup.

I got rid of the muddy mid range when I pulled the speakers away from the wall. I will kill one of the subs and see what I get though. I my vsx is in my ht setup. My 2channel is a carver pre and amp

Yes Inspector the stands are spiked

[recoveryone]

Looking forward to hear your results

[xftman]

Lucky you!!! I have a similar my size extra bed room I would like to 2 channels music room. But my wife wants to keep as guest room which 99% of time unoccupied and ask me to renovate my unfinished basement.

[specd_out]

Man if I had a basement i would be all over that.

[michael1947]

Nice room and a great looking chair. Did you get one?

[specd_out]

Not yet. Acoustic panels are first on my list. I am picking up the supplies for them today. The acoustics in this room suck. I dont enjoy listening in there right now. Thus the reason for my rush on building the panels

[specd_out]

Just wanted to update this with some more progress. I am building 8 2x3x4 acoustic panels. Four of the panels will be bass traps placed across the two front corners. They will go nearly floor to ceiling. Two will be for first reflections and two will be hung in the rear of the room. Today I got all the frames built and tomorrow I will be sanding the rough edges.

I ordered the Roxul Safe and Sound batts, and I am hoping they come in soon. My wife picked out some fabric. She said it will complement the color we plan on painting the room. I dunno though. I have my doubts. I also found two posters I plan on framing.

[jeremymarcinko]

Heck yea man I have that rat pack poster framed above my bar.

[headrott]

"Eeee-Oh-Eleven."

[specd_out]

UPDATE:

I finished all the wall treatments. I have floor to ceiling bass traps, and 4 acoustic panels. Two on the first reflection points and two behind the chair.

I used roxul safe and sound which is 4'x8'x3". Framed it and wrapped it in fabric. Total cost for all materials was just under $130 for 8 panels.

The results where amazing. Every issue I was having has been fixed. Imaging has improved. Instruments are more discernible and its easier to find their location. The bass was the biggest change. That room seemed like a giant bass void. I had to have the subs maxed to get it where I liked it. As soon as the panels went up I had to turn the subs down to just below half.

I am very happy. I would advise everyone who can to do this before upgrading anything else. It is the biggest bang for the buck improvement I have found so far.
Also if you plan on doing this DL the Joann's app. They always have coupons for 40% or 50% off material.






This is how I hung the panels on the door and the closet


My favorite part. My Ikea chair. So comfortable and stylish. I love this thing

[organ]

Nice. I like the design on the fabric you used.
