Specification
- Speaker Type Performance Center Channel
- UOM (Sold As) Each
TRANSDUCER
- Tweeter 1" Pinnacle Ring Radiator
- Mid-range/Mid-bass -
- Woofers Two 6 ½” Turbine Cone
- Overall Frequency Response 36Hz - 50kHz
- Frequency Response (-3dB limits) 48Hz - 39kHz
- Recommended Amplifier Power 20 - 200W
- Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
- Minimum Impedance (ohms) 4.1Ω
- Sensitivity (2.83V/1m) 89dB
CROSSOVER
- Tweeter/Mid-range Crossover Frequency 2500
- Mid-range/Mid-bass Crossover Frequency -
MEASUREMENTS
-
Product Dims W x H x D (Includes width of feet)
615 x 196.6 x 350mm
24.2 x 7.8 x 13.8 in - Product Weight (each) 32.8 lbs/14.9 kg
- Shipping Weight 39.5 lbs/17.9 kg
CABINETRY
- New CRC (Mid-Range Enclosure Type) -
- Mid-Bass / Woofer Enclosure Type Dual Rear X-Ports
- Available Finishes Black / Walnut
- Feet Rubber pads
- Wall-Mountable (keyhole slots) No
- Binding Posts: Nickel-plated 5-Way Single
Certifications Non-Safety and Regulatory
- Hi-Res Certified Yes
- IMAX Certified Yes
-
Shipping Dims (WxHxD)
740 x 483 x 293mm
(29.1 x 19 x 11.5) in
