HTS 12 Subwoofer
- Total Pieces 1
- Height 18.5" (46.99 cm)
- Width 17.126" (43.5 cm)
- Depth 18.11" (46 cm)
- Weight 49.9 lbs (22.63 kg)
- Subwoofer Array Driver Enclosure Type Power Port Bass Vented
- Subwoofer Array Driver Complement •(1) 12" (30.48 cm) d (Round) Polypropylene Dynamic Balance and Klippel optimized driver - Subwoofer
- Peak Power 400 Watts
- Continuous Power 200 Watts
- Amplifier Class Class D
- Total Frequency Response 22 Hz → .180 Hz
- Nominal Impedance 8 ohms
- Lower and Upper -3dB Limits 28 Hz → .120 Hz
- IO Button Location Back Panel
-
Adjusts
\t•Volume +/-
•Low Pass Filter (40Hz-160Hz)
•Phase (0/180°)
•Power: Auto on/off
•Power: DC control (12V trigger) -
Audio Inputs
\t•LFE (Unfiltered)
•Stereo Line Level - (2) RCA - US Power Cycle Energy Star Compliant with Auto Standby (.5W)
Signature Elite ES20 Bookshelf
- Qty Included Pair
- Width 8.5" (21.59 cm)
- Height 14.8" (37.59 cm)
- Depth 13.8" (35.05 cm)
- Weight 17 lbs (7.71 kg)
-
Driver Complement
• (1) 1" (2.54 cm) d (Round) Terylene High-Res Dome Tweeter
• (1) 6.5" (16.51 cm) d (Round) Dynamic Balance Mica Reinforced Polypropylene Driver - Driver Enclosure Type PowerPort Bass Vented
- Impedance Compatible with 4 and 8 ohm outputs
- Recommended Amplifier Power Per Channel 20 watts → 150 watts
- Sensitivity (1 watt @ 1 meter) 88 dB
- Crossover Frequency 2,500 Hz
- Total Frequency Response 44 Hz → 40,000 Hz
- Inputs (1) Pair of 5-way Binding Posts - Gold Plated
Signature Elite ES30 Center
- Qty Included 1
- Width 20" (50.8 cm)
- Height 7.5" (19.05 cm)
- Depth 10.6" (26.92 cm)
- Weight 19 lbs (8.62 kg)
- Orientation Horizontal
-
Driver Complement
• (1) 1" (2.54 cm) d (Round) Terylene High-Res Dome Tweeter
• (2) 5.25" (13.34 cm) d (Round) Dynamic Balance Mica Reinforced Polypropylene Drivers - Driver Enclosure Type PowerPort Bass Vented
- Impedance Compatible with 4 and 8 ohm outputs
- Recommended Amplifier Power Per Channel 20 watts → 150 watts
- Inputs Single gold-plated 5-way binding posts
- Max Sensitivity (1 watt @ 1 meter) 89 dB
- Crossover Frequency 2500 Hz
- Total Frequency Response 55 Hz → 40,000 Hz
Signature Elite ES60 Tower x2
- Qty Included 1
- Width 8.5" (21.59 cm)
- Height 44.5" (113.03 cm)
- Depth 15.7" (39.88 cm)
- Weight 52 lbs (23.59 kg)
- Width with Base 11.7" (29.7 cm)
-
Front Array Driver Complement
• (1) 1" (2.54 cm) d (Round) Terylene High-Res Dome Tweeter
• (3) 6.5" (16.51 cm) d (Round) Dynamic Balance Mica Reinforced Polypropylene Drivers - Impedance Compatible with 4 and 8 ohm outputs
- Recommended Amplifier Power Per Channel 20 watts → 300 watts
- Inputs Dual gold-plated 5-way binding posts
- Sensitivity (1 watt @ 1 meter) 90 dB
- Crossover Frequency 2,500 Hz
- Total Frequency Response 36 Hz → 40,000 Hz
