OVERALL
- Total Pieces 3
-
Included Accessories
• (1) Waterproof IP68 Rated Junction box
• (1) Sub100 Weatherproof Aluminum Grille
• (2) Sat300 Ground Stakes
• (2) Sat300 Security Plates
• (2) Sat300 Pendant Caps
• (2) Sat300 Rubber Bumpers
• (2) Sat300 Eyebolts
• (4) Sat300 Fasten Connectors
• (1) Sat300 Mounting Template
• (2) Sat300 #10 Pan Head Screws
• (4) Sat300 #6 Pan Head Screws
• (2) Sat300 Lock Washers
• (8) Wire Nuts
• (1) Owner's Manual - Cabinet Warranty 5 years
- Drivers Warranty 5 years
- Original Purchaser Only Yes
- Carton 1 -
ATRIUM SUB100
- Total Pieces 1
- Subwoofer Array Driver Enclosure Type Acoustic Suspension with Color-Impregnated Resin Shell
- Subwoofer Array Driver Complement • (1) 10" (25.4 cm) d (Round) Long-throw Dynamic Balance composite cone driver with dual voice coils and butyl rubber surround - Subwoofer - Voice Coil 2" (5.08 cm) d
- Height 11" (27.94 cm)
- Width 16.9" (42.93 cm)
- Depth 16.9" (42.93 cm)
- Weight 16.75 lbs (7.6 kg)
- Nominal Impedance 8 ohms
- Sensitivity (1 watt @ 1 meter) 88 dB
- Lower and Upper -3dB Limits 50 Hz → 110 Hz
- Recommended Amplifier Power Per Channel 10 watts → 200 watts
- Peak Power Handling 200 watts
- Midrange/Woofer Crossover Frequency 150 Hz
- Power Handling (per channel) 10 watts → 200 watts
- Mounting Type Security eyebolt
- Available Orientations Horizontal
- Mounting Type Keyhole Slots
- Available Orientations Horizontal
ATRIUM SAT300
- Total Pieces Pair
- Height 7" (17.78 cm)
- Width 5.5" (13.97 cm)
- Depth 8.4" (21.34 cm)
- Weight 3.25 lbs (1.47 kg)
- Driver Enclosure Type Mineral-filled polypropylene cabinet
-
Driver Complement
• (1) 3.5" (8.89 cm) d (Round) Dynamic Balance driver with extended motor structure, composite cone and butyl rubber surround - Mid/Woofer
• (1) 0.75" (1.91 cm) d (Round) Dynamic Balance polyurethane tweeter with neodymium magnet - Tweeter - Waterproof Rating IPX66
- Total Frequency Response 100 Hz → 22,000 Hz
- Nominal Impedance 8 ohms
- Sensitivity (1 watt @ 1 meter) 83 dB
- Lower and Upper -3dB Limits 115 Hz → 20,000 Hz
- Recommended Amplifier Power Per Channel 10 watts → 100 watts
- Mounting Type Wall bracket
- Mounting Type Hanging pendant
- Mounting Type -
