OVERALL
- Total Pieces 1
- Cabinet Warranty 5 years
- Drivers Warranty 5 years
- Original Purchaser Only Yes
- Carton 1 20 lbs (9.07 kg)
CENTER
- Qty Included 1
- Availability US
- Orientation Horizontal
- Height 4.25" (10.8 cm)
- Width 16.688" (42.39 cm)
- Depth 3.813" (9.68 cm)
- Weight 4.5 lbs (2.04 kg)
- Enclosure Type Curved Enclosure with PowerPort Bass Venting
-
Front Array Driver Complement
• (2) 3.25" (8.26 cm) d (Round) - Midrange
• (1) 0.74" (1.88 cm) d (Round) - Tweeter - Total Frequency Response 90 Hz → 24 Hz
- Nominal Impedance 8 ohms
- Sensitivity 1 watt 1 meter 91 dB
- Lower and Upper -3dB Limits 120 Hz → 20 Hz
- Audio Inputs -
- Ethernet Yes
- Speaker Inputs (1) 5-way Binding Posts - Gold-Plated
- Mounting Type 1/4" 20 Threaded Insert
- Available Orientations Horizontal
-
Mounting Location
• Back of Speaker
• Top of Speaker
Near: Top, Center - Mounting Type Keyhole Hanger
- Available Orientations Horizontal
- Mounting Location Back of Speaker - Near: Top, Left, Right, Center
- Recommended Amplifier Power Per Channel 10 watts → 125 watts
SATELLITES
- Qty Included 4
- Availability US
- Orientation Vertical
- Height 7.125" (18.1 cm)
- Width 4.125" (10.48 cm)
- Depth 5.188" (13.18 cm)
- Weight 3 lbs (1.36 kg)
- Enclosure Type Steel Plate Reinforced Urged Enclosure with PowerPort Bass Venting
-
Front Array Driver Complement
• (4) 3.25" (8.26 cm) d (Round) - Mid/Woofer
• (4) 0.75" (1.91 cm) d (Round) - Tweeter - Mounting Type 1/4" 20 Threaded Insert
- Available Orientations Vertical
-
Mounting Location
• Back of Speaker
• Top of Speaker
Near: Top, Center" - Mounting Type Keyhole Hanger
- Available Orientations Vertical
-
Mounting Location
• Back of Speaker
• Top of Speaker
Near: Top, Center
