OVERALL
- Total Pieces 1
- Electronics Warranty 3 years
- Cabinet Warranty 5 years
- Drivers Warranty 5 years
- Original Purchaser Only Yes
- Carton 1 41 lbs (18.6 kg)
CENTER
- Qty Included 1
- Availability US Internationally
- Orientation Horizontal
- Height 4" (10.16 cm)
- Width 15" (38.1 cm)
- Depth 3.5" (8.89 cm)
- Weight 3.35 lbs (1.52 kg)
-
Front Array Driver Complement
• (2) 2.5" (6.35 cm) d (Round) - Midrange
• (1) 0.5" (1.27 cm) d (Round) - Tweeter - Total Frequency Response 40 Hz → 22,000 Hz
- Lower and Upper -3dB Limits 45 Hz → 20 Hz
- Mounting Type 1/4" 20 Threaded Insert
- Available Orientations Horizontal
- Mounting Location Back of Speaker
- Mounting Type Keyhole Hanger
- Mounting Type Horizontal
- Mounting Location Back of Speaker
- Peak Power Handling 100 watts
- Recommended Amplifier Power Per Channel 10 watts → 100 watts
- Audio Inputs -
- Ethernet Yes
- Speaker Inputs (1) 5-way Binding Posts - Plastic Caps
SATELLITES
- Qty Included 4
- Availability US
- Orientation Vertical
- Height 6.5" (16.51 cm)
- Width 3.75" (9.53 cm)
- Depth 4.875" (12.38 cm)
- Weight 1.85 lbs (0.84 kg)
- Driver Enclosure Type Non-Resonant Composite w/Time-Aligned Geometry And Aperiodic Tuned Port
-
Driver Complement
• (1) 2.5" (6.35 cm) d (Round) - Midrange
• (1) 0.5" (1.27 cm) d (Round) - Tweeter - Total Frequency Response 40 Hz → 22 Hz
- Lower and Upper -3dB Limits 45 Hz → 20 Hz
- Mounting Type 1/4" 20 Threaded Insert
- Available Orientations Vertical
- Mounting Location Back of Speaker
- Mounting Type Keyhole Hanger
- Available Orientations Vertical
- Recommended Amplifier Power Per Channel 10 watts → 100 watts
- Audio Inputs -
- Ethernet Yes
- Speaker Inputs (1) 5-way Binding Posts - Plastic Caps
SUBWOOFER
- Qty Included 1
- Availability US
- Orientation Vertical
- Height 13.875" (35.24 cm)
- Width 12.5" (31.75 cm)
- Depth 12.5" (31.75 cm)
- Weight 20.5 lbs (9.3 kg)
- Subwoofer Array Driver Enclosure Type Downward Firing Vented Port
- Subwoofer Array Driver Complement • (1) 8" (20.32 cm) d (Round) - Subwoofer
- Total Frequency Response 40 Hz → 22 Hz
- Lower and Upper -3dB Limits 45 Hz → 22 Hz
- Audio Inputs -
- Ethernet Yes
- Speaker Inputs (1) 5-way Binding Posts - Plastic Caps
