DRA-800H

Name: DRA-800H
Brand: Denon
SKU: 137271-01-00-101
Price: 399.00 USD
Availability: OutOfStock

2.2 Ch. 100W 4K AV Receiver with HEOS® Built-in

$399.00 ~~Price reduced from $599.00~~

Select Quality

Color

Black

Quantity

Availability:

Item Unavailable

Out of Stock

Coming Soon

Denon stereo receiver built with Hi-Fi amplification seamlessly integrates with the latest Hi-Res audio, wireless, voice control and AV receiver technologies including five 4K Ultra HD HDMI inputs.

DRA-800H

$399.00 ~~Price reduced from $599.00~~

DRA-800H

Details & Specifications

Multichannel Surround

Sound Enhancements

Network

Media Server Yes
HEOS Wireless Multi-Room Technology Yes
Bluetooth Re-transmit for Bluetooth headphones Yes (update)
Alexa / Google Voice Assistant / Apple HomePod Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming Yes (2.8/5.6MHz)
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV ,ALAC ,DSD)
Photo Streaming (JPEG) No
Internet Radio Yes (TuneIn)
Spotify* Yes (connect)
Pandora Yes
SiriusXM* Yes
Other Streaming Services * Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
HEOS App Control Yes
Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote
Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back / Front 5 / No
HDCP 2.2 support Yes (HDCP 2.3)
HDMI Outputs: Main / Zone 1 / No
Video Conversion Analog -> HDMI No
Analog to HDMI Scaling No
HDMI to HDMI Scaling No
GUI Overlay on HDMI Yes
HDMI: 3D / 4K / CEC / ARC / InstaPrevue Yes / Yes / Yes / Yes / No
Enhanced ARC No
HDR / HLG / Dolby Vision Yes (HDR10) / Yes / No
ALLM (Auto Low Latency Mode) Pass-through for gaming Yes
3D Signal Pass-through Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / No / Yes
HDMI Pass-Through in Standby Mode Yes
Picture Adjust / Noise Reduction No / No
CEC Yes
DSD Audio Capability No
Audio Return Channel Yes
Auto LipSync Yes

Multi-room CI

Others

Inputs Outputs

Composite In / Out No / No
Component In / Out No / No
HDMI In / Out 5 / 1
Multi-room Video Out: Video / HDMI No / No
2 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 1
Multi-room Out: Analog / Digital 1 / 0
Multichannel Preout Yes (0.2) / No
Subwoofer Out 2
7.1 Multichannel Input No
Speaker Terminal: Gold Plated Screw / Regular Screw Yes / No
Number of Speaker Terminals 4
Speaker A / B Yes
Bi-amp Drive No
Multi-Room Speaker Terminal No
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone Yes / No / No
AM/FM Tuner Yes

Specifications

General

Metal Front Panel No
System Remote Control RC-1235
Pre-programmed / Learnable / LCD Display No / No / No
Power Consumption in W TBD
Power Consumption No-Sound (ECO On / Off) in W TBD
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches 17.1× 13.3 × 6
( 17.1 x 13.3 x 8.5)
Weight in LBS 18.3
Power Supply AC 120 V, 60 Hz
Speaker impedance 4 - 16Ω/ohms
Input sensitivity 200 mV
Frequency response 10 Hz - 100 kHz — +1, –3 dB (Direct mode)
S/N Ratio 98 dB (IHF-A weighted, Direct mode)
FM section (Tuning frequency range) 87.5 - 107.9 MHz
AM section (Tuning frequency range) 520 kHz – 1710 kHz
