OVERALL
- Total Pieces 1
- Drivers Warranty 5 years
- Warranty Yes
- Carton 1 5.75" (14.61 cm) h x 6" (15.24 cm) w x 18.5" (46.99 cm) d - 7 lbs (3.18 kg)
CENTER CHANNEL
- Qty Included 1
- Orientation Horizontal
- Height 4.312" (10.95 cm)
- Width 16.687" (42.38 cm)
- Depth 3.937" (10 cm)
- Weight 4.7 lbs (2.13 kg)
-
Driver Complement
• (2) 3.25" (8.26 cm) d (Round) Dynamic Balance aerated polypropylene cone with Extended Linear Motion voice coil driver - Mid/Woofer
• (1) 1" (2.54 cm) d (Round) Dynamic Balance ring radiator tweeter - Tweeter - Total Frequency Response 90 Hz → 31,000 Hz
- Nominal Impedance 8 ohms
- Sensitivity (1 watt @ 1 meter) 90 dB
- Lower and Upper -3dB Limits 115 Hz → 28,000 Hz
- Mounting Type 1/4 in - 20 Threaded Insert & Keyhole Hanger
- Available Orientations Horizontal
- Audio Input -
- Speaker Inputs (1) Pair of 5-way binding posts with metal caps - Gold-plated
